How do I know which current transformer to place on which phase conductor?

*NOTE: The information below is directed towards installers. Only trained electricians are allowed to install Ferroamp’s products.


Answer:


During commissioning, the configuration of the current transformers (CTs) should be done from the EnergyHub display. This process automatically detects on which phase conductor and in which direction the current transformers are mounted. Therefore, during installation, the three transformers can be mounted on any phase conductor and in any direction.
