Can you extend the cable to the Rogowski current transformers?

*NOTE: The information below is directed towards installers. Only trained electricians are allowed to install Ferroamp’s products.

Answer:

Yes, they can be extended with a twisted pair and shielded cable, such as a CAT6 STP cable. However, they should not be extended more than about 100 meters so as not to have too high an impact on the measurement accuracy.
