What type of fuses are used in the DC distribution/ESS PowerCase?

*NOTE: The information below is directed towards installers. Only trained electricians are allowed to install Ferroamp’s products.


Answer:


Ferroamp's DC distributions and ESS PowerCase are equipped with 15A, 1000V, gPV fuses. These can be replaced with 20 or 32A, 1000V gPV fuses. The dimensions of the fuses are 10x38 mm.
