Answer:

Each EnergyHub has a phase balancing capacity of 20 A regardless of size. The phase balancing capacity indicates how much current can be transferred between phases.

For more information on how phase balancing works, read here.

For our EnergyHub rack cabinets, this means it is possible to have up to 100 A of phase balancing capacity.

Example:

• An EnergyHub Cabinet 24U containing three EnergyHub XL modules provides 60 A of phase balancing capacity.
• An EnergyHub Cabinet 42U containing five EnergyHub XL modules provides 100 A of phase balancing capacity.
